S.M. Scientific Instruments (P) LTD

Under Counter Pharmacy Refrigerator 2℃~8℃ SMI-165UCPR-129EL

Home ≫Ultra Low Temp.>Under Counter Pharmacy Refrigerator 2℃~8℃ SMI-165UCPR-129EL



Under Counter Pharmacy Refrigerator 2℃~8℃ SMI-165UCPR-129EL

CLICK TO SCAN

Overview

Jindal Under Counter Pharmacy Refrigerator 2℃~8℃ SMI-165UCPR-129EL gives you  a brand new appearance and is designed in a smart under-counter size. This small undercounter medical refrigerator is equipped with an intelligent temperature controller and brings out constant temperature. It has a transparent double-layer tempered glass door with the features of anti-condensation and electrical heating. There are multiple alarm functions to ensure safety of storage.

Accurate Control System
This Under Counter Pharmacy Refrigerator 2℃~8℃ SMI-165UCPR-129EL for medicine comes with a high precision temperature control system with high sensitive sensors. And it can well keep the temperature inside the cabinet in the range of 2℃~8℃. We design the pharmaceutical refrigerator with a high brightness digital temperature and humidity display for automatic temperature control and ensure the display accurately in 0.1℃.

Powerful Refrigeration System
The medical / lab refrigerator is equipped with a brand new compressor and condenser, which is for better cooling performance and well keeps the temperature uniformity within 1℃. It is an air cooling type with the feature of auto-defrost. And the HCFC-FREE refrigerant brings out more effective refrigeration and ensures environmentally friendly.

Ergonomic Operation Design
It has a front opening lockable door with a full height handle. The inside of the pharmacy refrigerator is designed with a lighting system for easy look. The light will turn on while the door is opened, and the light will turn off while the door is closed. The cabinet is made of high quality steel, and the inner side material is Aluminum plate with spraying(Optional stainless steel), which is durable and easy to clean.

Features

  • Perfect audible and visual alarms including high and low temperature alarm, power failure alarm, sensor failure alarm, and door ajar alarm.
  • With 3 high-quality steel wire shelves, the shelves are adjustable to any height for satisfying different requirements.
  • Standard with built-in USB datalogger, remote alarm contact and RS485 interface for monitor system.
  • 1 cooling fan inside, working while the door is closed, stopped while the door is opened.
  • The CFC-free polyurethane foam insulating layer is environmentally friendly.
  • Adopt double layer foamed solid door, high efficiency heat preservation.
  • The medical refrigerator is equipped with 2 sensors. When the primary sensor fails, the secondary sensor will be activated immediately.
  • The door is equipped with a lock preventing unauthorized opening and operation.

Scope of Application

Mini refrigerator for medicine storage,Suitable for storage of biological products, vaccines, drugs, reagents, and more; Suitable for use in pharmacies, pharmaceutical factories, hospitals, centers for disease prevention & control, clinics, etc.

Technical Data:

Model
SMI-165UCPR-129EL
Cabinet
Upright
Capacity(L)
129
Internal Size(W*D*H)mm
554*510*588
External Size(W*D*H)mm
650*625*810
Package Size(W*D*H)mm
720*703*880
NW(Kg)
51/56
Performance
Temperature Range
2~8℃
Ambient Temperature
16-32℃
Cooling Performance
5℃
Climate Class
N
Controller
Microprocessor
Display
Digital Display
Refrigeration
Compressor
1pc
Cooling Method
Air cooling
Defrost Mode
Automatic
Refrigerant
R600a
Insulation Thickness(mm)
L/R:48,B:50
Construction
External Material
PCM
Inner Material
Aluminum plate with spraying/Stainless steel(optional)
Shelves
3 (coated steel wire shelf)
Door lock with key
Yes
Door with heater
Yes
Lighting
LED
Access Port
1pc. Ø 25 mm
Data logging/Interval/Memory capacity
USB/Record every 10 minutes / 1000,000data
Casters
2+2( leveling feet)
Alarm
Temperature
High/Low temperature, High ambient temperature, Condenser overheating
Electrical
Power failure, Low battery
System
Sensor error, Door ajar, Built-in datalogger USB Failure, Communication failure
Accessories
Standard
RS485, Remote alarm contact

Product Brochure

Product Brochure Link here
