Touch Screen ULT Vaccine Freezer -40~-86℃ SMI-165ICS-SA-396

Home ≫Ultra Low Temp.>Touch Screen ULT Vaccine Freezer -40~-86℃ SMI-165ICS-SA-396

Touch Screen ULT Vaccine Freezer -40~-86℃ SMI-165ICS-SA-396

CLICK TO SCAN

Description

7” Screen Control System

7-inch Intelligent HD display touch screen,user-friendly interface and more accurate temperature control, with Bluetooth, Wi-Fi and other functions, more convenient operation and more comprehensive functions.

The high-precision microcomputer control system and platinum resistor sensors enable users to set temperature inside the cabinet within a range from -40 to -86℃.

Refrigeration System

The imported high-efficiency compressor and EBM fan are energy-saving and highly efficient.

The large finned condenser with a space between fins ≤ 2mm, providing effective heat dissipation.

Security System

The perfect audible & visual alarm system , high and low temperature ,sensor failure ,power failure ,low battery ,door ajar ,main board communication error, high ambient temperature ,built-in data logger USB failure,samples out of date notification etc.

The compressor start delay and stopping interval protection can ensure reliable operation.

Both the touch screen controller and key- board controller have password protection which can prevent any adjustment of operation without permission.

Three-dimensional Thermal Insulation

The six sides of the cabinet are made from high -efficiency VIP vacuum thermal insulation plate, and the thermal insulation design of the inner door made from foaming material and the outer door system was awarded with multiple patents, which can improve the thermal insulation performance of the freezer.

Human-oriented

The new designed assisting handle and vacuum release port let the freezer be operated single- handed to open and close the outer door.

The newly added file box makes recording easier and more convenient.

The liner made from stainless steel for medical use is low-temperature tolerant and corrosion-resistant, which has a long service life and is easy to clean.

The universal casters and leveling feet design are more convenient for movement and fixation.

Optional Accessory(WiFi/Bluetooth printer/Mechanical lock/Swipe card/Fingerprint)

Connect WiFi to upload data to the cloud space, monitor the device, check the status of the refrigerator faster, and ensure the safety of the samples.Optional Bluetooth printer, real-time export temperature data, temperature graph, setting operation and other data, to understand the freezer operating status.Optional functions such as card unlocking, fingerprint unlocking, and facial recognition unlocking are available to facilitate quick access to samples.

Features

  • Intelligent control system.
  • For COVID-19 vaccine storage.
  • The new generation of ultra-low temperature refrigeration system can ensure fast refrigeration and was awarded with the Second Prize under State Technological
  • Invention Award.
  • Imported high-efficiency compressor + separated evaporator + composite heat exchanger +optimized fractional condensation & separation system + high-efficiency thermal insulation.
  • System can save energy and reduce power consumption of the freezer by 40%.
  • Low-noise direct cooling circuit + suspension frame & sound absorbing compartment & low-noise fan can reduce noise generated by the entire freezer to the largest extent.

 Scope of Application

This Android Control System  Ultra low Energy saving freezer can be used as laboratory freezer, ultra low medical freezer and deep freezer, suitable for application in hospitals,  health and disease prevention systems, colleges and universities, research institutions, the electronic industry, laboratories in colleges & universities, biological engineering, and more.

SMI-165ICS-SA-396 is the current hot ultra-low temperature freezer for COVID-19 vaccine storage.

Specifications

Model
SMI-165ICS-SA-396
Capacity(L)
396
Internal Size(W*D*H)mm
440*696*1266
External Size(W*D*H)mm
785*1041*1947
Package Size(W*D*H)mm
890*1165*2158
NW(Kg)
237/315(wood pacaking)
Performance
Temperature Range
-40~-86℃
Ambient Temperature
16-32℃
Cooling Performance
-86℃
Climate Class
N
Controller
Microprocessor
Display
HD intelligent touch screen
Refrigeration
Compressor
1pc
Cooling Method
Direct Cooling
Defrost Mode
Manual
Refrigerant
Mixture Gas
Insulation Thickness(mm)
L/R: 130, B: 130
Construction
External Material
Sprayed steel plate
Inner Material
Stainless Steel
Shelves
3(stainless steel)
External Lock
Yes
Access Port
2pcs. Ø 25 mm
Door lock with key
Yes
Backup Battery
Yes
Data logging/Interval/Memory capacity
USB/Record every 5 minute / 10 years
Casters
4+(2 leveling feet)
WIFI
Yes
Alarm
Temperature
High/Low temperature,High ambient temperature
Electrical
Power failure,Low battery
System
Sensor failure,Main board communication error,Condenser overheating,Door ajar
Accessory
Standard
RS485, Remote alarm contact
Options
Chart recorder, CO2 backup system
