Pharmacy Refrigerator‎ 2℃ to 8℃ SMI-165PR-314EL

Home Ultra Low Temp.>Pharmacy Refrigerator>Pharmacy Refrigerator‎ 2℃ to 8℃ SMI-165PR-314EL

Pharmacy Refrigerator‎ 2℃ to 8℃ SMI-165PR-314EL

CLICK TO SCAN

Description

The Jindal Pharmacy Refrigerator SMI-165PR-314EL is a pharmaceutical-grade refrigerator designed for vaccines, medical offices, laboratories, clinics, and scientific institutions. It is built for quality and durability, meeting the stringent guidelines required for medical and laboratory-grade refrigeration. The SMI-165PR-314EL offers a spacious 314L interior with adjustable 4+1 shelves for efficient storage capacity. This medical and laboratory refrigerator is equipped with a high-precision microcomputer temperature control system, ensuring a stable temperature range of 2℃ to 8℃. Additionally, it features a high-brightness digital temperature display, offering precise readings with an accuracy of 0.1℃

Advance Air Cooling Refrigeration System

The SMI-165PR-314EL pharmaceutical-grade refrigerator features a multi-duct vortex refrigeration system and a finned evaporator, which effectively prevent frost buildup and greatly enhance temperature uniformity. The high-efficiency air-cooled condenser, along with the finned evaporator, ensures fast and efficient cooling performance.

Smart Audio-Visual Alarm System

This vaccine refrigerator is equipped with multiple audible and visual alarm functions, including high/low temperature alarm, power failure alarm, low battery alarm, door ajar alarm, high ambient temperature alarm, and communication failure alarm, among others.

Advanced Technology Design

The refrigerator features a double-layer foamed solid door for high-efficiency heat preservation. It is designed with high-quality shelves made of PVC-coated steel wire, complete with tag cards for easy cleaning. An integrated invisible door handle adds to the elegant appearance of the unit.

Features

  • The seven temperature probes ensure highly precise temperature control with minimal fluctuation, thereby enhancing safety.
  • It is equipped with a USB export interface that automatically stores temperature data from the previous month to the current month in PDF format.
  • When a USB drive is connected, temperature data can be continuously and automatically stored for more than two years.
  • The interior lighting system, featuring double LED lights, provides excellent visibility inside the cabinet.
  • A built-in test port offers added convenience for users when measuring internal cabinet temperatures.
  • With a large 314L capacity, this unit provides ample storage space for vaccines, medications, reagents, and other medical or laboratory materials.
  • The refrigerator features a 100% CFC-free design, making it environmentally friendly and free of ozone-depleting chemicals.

Technical Data:

Model

SMI-165PR-314EL

Cabinet Capacity

Upright

Capacity(L)

314

Internal Size(W X D X H)mm

580 X 533 X 1122

External Size(W X D X H)mm

650 X 673 X 1762

Package Size(W X D X H)mm

717 X 732 X 1815

NW/GW(Kgs)

87/99

Temperature Range

2 to 8℃

Ambient Temperature

16 to 32℃

Cooling Performance

5℃

Climate Class

N

Controller

Microprocessor

Display

Digital display

Compressor

1 Nos.

Cooling Method

Air cooling

Defrost Mode

Automatic

Refrigerant

R600a

Insulation Thickness(mm)

R/L:35,B:52

External Material

PCM

Inner Material

HIPS

Shelves

4+1 (coated steel wired shelf)

Door lock with key

Yes

Lighting

LED

Access Port

1pc. Ø 25 mm

Casters

4+(2 leveling feet)

Data logging/Interval/Capacity

USB/Record every 10 minutes/100,000data

Door with heater

Yes

Temperature

High/Low temperature, High ambient temperature

Electrical

Power failure, Low battery

System

Sensor error, Door ajar, Built-in USB datalogger  Failure, Condenser overheating

Standard

RS485, Remote alarm contact, Backup battery

Product Brochure

Product Brochure Link here
