JINDAL latest design medical refrigerators are designed to meet the requirements of laboratory. These are silent operation refrigerators specifically designed to store medicines, drugs, & other valuable vaccines, test kits etc within a temperature range of 2°C to 8°C.
Model | SMI-165MR(I) | SMI-165MR (II) | SMI-165MR(III) | SMI-165MR (IV) | SMI-165MR (V) |
External Size (W X D X H) mm | 500 X 550 X 1300 | 580 X 575 X 1810 | 620 X 575 X 1980 | 1220 X 630 X 1885 | 1220 X 860 X 1885 |
Capacity | 160L | 250L | 310L | 588L | 1000L |
Temp. Range | 2oC to 8oC | 2oC to 8oC | 2oC to 8oC | 2oC to 8oC | 2oC to 8oC |
Temp. Accuracy | 0.10C | 0.10C | 0.10C | 0.10C | 0.10C |
Control System | Microprocessor Control, Large Screen LED Display | ||||
Alarm (Optional) | Audible and visual alarm for: High and low temperature, Power failure alarm, Sensor failure, Door ajar | ||||
Refrigeration Type | Forced air refrigeration system | ||||
Refrigerant | R600a, CFC Free | R600a, CFC Free | R600a, CFC Free | R134a, CFC Free | R134a, CFC Free |
Condenser & Evaporator | Bundy tube condenser | High efficiency air cooled condenser, made of copper | |||
Defrost | Auto defrost | Auto defrost | Auto defrost | Auto defrost | Auto defrost |
Door | Glass Door | Glass Door | Glass Door | Glass Door | Glass Door |
Construction | Structure | Unibody Design & Mono-assembly foaming (Rigid polyurethane insulation material) | |||
Construction (Internal Material) | ABS Medical Grade Plastic/Embossed Aluminium | ||||
Construction (External Material ) | Cold-rolled steel coated with anti-bacteria powder | ||||
Shelves | 4 pcs | 4 pcs | 5 pcs | 10 pcs | 10 pcs |
Consumption | 136W | 170W | 180W | 180W | 180W |
Power Supply | AC110/220V±10 , 50/60Hz | ||||
Standard Accessory | LED Lamp, shelves, door keys | ||||
Optional Accessory | ABS Medical Grade Plastic/Embossed Aluminium | ||||
Package Size (W X D X H)mm | 590 X 594 X 1380 | 670 X 650 X 1870 | 700 X 650 X 2030 | 1340 X 750 X 2100 | 1340 X 980 X 2100 |
Gross weight | 51kg | 68kg | 84kg | 248kg | 280kg |
Product Brochure Link here
