Home ≫Ultra Low Temp.> Refrigerator Cum Freezer > Combined Refrigerator and Freezer SMI-165RCF
CLICK TO SCAN
JINDAL 2℃ to 8℃/-10℃ to -40℃ combination refrigerator freezer SMI-165RCF is designed with separate control of refrigeration and freezing. It comes with two compressors and separate control of upper refrigeration chamber and lower freezer chamber. This fridge freezer combo adopts Freon-free refrigeration, which is environmentally friendly and energy-saving. And it comes with updated thermal insulation with CFC-free polyurethane foam technology and thicker insulation layer. The high-precision computerized temperature control helps you to set the upper temperature in a range of 2℃ to 8℃ and lower temperature in a range of -10℃ to -40℃. Jindal 2℃ to 8℃/-10℃ to -40℃ Medical Refrigerator & Freezer SMI-165RCF is specially designed for reagent and other medical and laboratory materials storage.
The digital temperature and humidity are displayed independently, and operating status can be viewed and checked clearly. You are able to set the high temperature or low temperature alarm points on the medical grade refrigerator freezer freely based on your needs. And you can set the upper temperature in a range of 2℃~8℃ and lower temperature in a range of -10℃~-40℃.
This commercial refrigerator freezer is equipped with CFC free refrigerant and high-efficiency compressor, ensuring rapid cooling, energy-saving and high efficiency. It has two compressor and separately controls the upper refrigeration chamber and lower freezing chamber. With no CFC polyurethane foaming technology and thicker insulation layer, it can ensure good insulation effect.
This medical refrigerator and freezer has 8 kinds of audible and visual alarm functions, including high\low temperature alarm, high ambient temperature alarm, sensor failure alarm, low battery alarm, communication failure, (USB) data download failure alarm, door ajar alarm, and power failure alarm, which ensure safer sample storage.
The instrument is designed to operate on 210-240V, 50Hz with single phase AC power supply.
Model | SMI-165RCF |
Cabinet type | Upright |
Capacity(L） | 519, R:323, F:196 |
Internal Size(W X D X H) mm | R:750 X 610 X 740，F:650 X 560 X 565 |
External Size(W X D X H) mm | 910 X 740 X 1972 |
Package Size(W X D X H) mm | 990 X 855 X 2140 |
NW/GW(Kgs) | 148 |
Performance | |
Temperature range | R: 2℃～8℃, F: -10℃～-40℃ |
Increment | 0.1℃ |
Cooling performance | R:5, F:-40 |
Display | Digital display |
Controller | Microprocessor |
Refrigeration | |
Compressor | 2 Nos. |
Cooling method | R: Forced air cooling, F:Direct cooling |
Defrost mode | R: Automatic, F:Manual |
Refrigerant | R:R600a, F:290 |
Insulation thickness(mm) | R:50, F:100 |
Construction | |
External material | PCM pre-coated plate material |
Inner material | Stainless steel 304 grade material |
Height adjustable shelves and drawers | R:3+1(Plastic steel wire), F:6(ABS) |
External lock | Yes |
Lighting | LED |
Test Hole | R: 1 F: 1 |
Casters | 4 (2 casters with brakes) |
Data logging/Interval/Memory capacity | USB/Record every 10 minutes/1000,000data |
Backup battery | Yes |
Door with heater | Yes |
Alarm | |
Temperature | High/Low temperature, High ambient temperature |
Electrical | Power failure, Low battery |
System | Sensor failure, Door ajar, Built-in USB datalogger failure, Communication failure |
Accessories | |
Standard | RS485, Remote alarm contact |
Optional | Printer |
Product Brochure Link here
