Stackable Shaking Incubator SMI-SSI

Home ≫ Shakers & Shaking Incubators >Stackable Shaking Incubator >Stackable Shaking Incubator SMI-SSI

Stackable Shaking Incubator SMI-SSI

CLICK TO SCAN

Description

JINDAL large capacity stackable shaking incubators are designed to meet the requirements of the industry. Incubator has double walled construction. Outer is made of Mild Steel with powder coated for anti-rusting and duly painted with best finishing with proper insulation. Inner Chamber is made of Stainless Steel 304G material. Inner and outer wall fill with PUF insulation to eliminate void pocket. The incubator has insulated double window door with glass window for easy visibility. The Incubator door has handle & casket for easy operate.

Previous
Next
Enquire Now

Latest Ergonomic Features

  • Auto restart on power restoration
  • Castor wheels for easy movability
  • Electrical circuit breaker
  • Safety features for over temperature Protection, Electrical leakage protection and Compressor Overload Protection
  • Compact, Independent & stackable up to 3 units
  • Temperature deviation indicators along with thermostat cut off, door switch, non-volatile memory with automatic power failure restart
  • Direct beltless drive system by Brushless DC motor for minimum vibration
  • Soft touch screen control
  • Counter balanced for high stability in an uneven load of different-sized flasks
  • Output signal to RS 232 enables data logging and computer controlled
  • Triple eccentric counter balanced drive
  • Clamps are made of single piece of stainless-steel material and leaves tied with spring
  • Universal platform capable to use assorted clamps
  • View samples without opening the door to avoid disturbance in internal conditions
  • Heating with long SS tubular heater
  • Noiseless operation
  • Electronic and mechanical components are protected from accidental spills

Additional Accessories

  • Static shelf
  • Power cable and plug tops
  • Power points
  • Light system
  • Clamps as per your requirement
    (100ml, 250ml,500ml, 1000ml,2000ml,5000ml,60000ml)
  • Voltage stabilizer

Technical Data

Model

SMI-SSI-159L

SMI-SSI-159R

Controller

Microprocessor Based PID

Microprocessor Based PID

Display

Digital LED

Digital LED

Circulation Mode

Forced Convention

Forced Convention

Shaking Mode

Orbital shaking

Orbital shaking

Drive Mode

Stepless Variable

Stepless Variable

Temp. Range

5°C to 80°C

5°C to 80°C

Temp. Accuracy

±0.1°C

±0.1°C

Temp. Uniformity

±0.25°C

±0.25°C

Rotating speed

50 ~ 400 rpm

50 ~ 400 rpm

Rotating Accuracy

±2rpm

±2rpm

Eccentric Throw

Φ25mm

Φ25mm

Refrigerant

CFC-Free, R134A

CFC-Free, R134A

Drive Mode

200W

200W

Cooling consumption

RT+5oC ~ 80oC

RT+5oC ~ 80oC

Heating Consumption

800W

800W

Timing Range

0 ~ 500 hours

0 ~ 500 hours

Shaking Plate size

450 * 765 mm

450 * 765 mm

Standard Capacity

10ml to 6L

10ml to 6L

Accommodated For Flask

6000ml,5000ml,2000ml, 1000ml, 6000ml, 500ml, 250ml, 125ml, 100ml & 50ml (as per your requirement)

Internal Material

Stainless Steel 304G

External Material

Cold-rolled steel with anti-bacterial power coating

Safety Function

Audio and visual alarm for set temperature ± 2°C, over-temperature, door open; Alarm for over-speeds; (User can mute Audible alarms) Independent over-temperature protector; Shutdown protection for door opening; Leakage or over-current protection, power failure

Interior illumination

Fluorescent Bulb

Consumption

960W

Power supply

AC110V/220-240V±10%, 50HZ

Internal Size (W*D*H)(mm)

660*765*660 (per unit)

800*600*550 (per unit)

External Size (W*D*H)(mm)

1100*800*1300 (per unit)

1300*800*700 (per unit)

Gross Weight (kg)

32KG

32KG
