Surgical Operating Table Hydraulic (Major head end control) SMI(HOSP)-589

Home ≫Hospital Furniture>Surgical Operating Table Hydraulic (Major head end control) SMI(HOSP)-589

Surgical Operating Table Hydraulic (Major head end control) SMI(HOSP)-589

CLICK TO SCAN

Product Description

Jindal’s latest design head end control operation Table is suitable to perform all opertaion positions such as abdominal, thyroid, gall bladder, kidney, neurosurgery, plastic surgery etc by obtaining flex, reflex, lateral tilt, trendlenburg, reverse trendlenburg and chair positions by the Anesthetist who can control these positions by sitting at the head end side of the table.
Sturdy and heavy duty base covered with S.S. Sheet for durability of table.
Single action double cylinder hydraulic pump which can be raised to minimum & Maximum height as mentioned in specification. It can be obtain by foot paddle.
Five section S.S. Top, with detachable legend section.
All the positions can be maneuvered from head end side by moving the handle as mentioned on the Indicator Dial.

Standard Accessories :

  • Anaesthetic Frame
  • Padded Side Supports
  • Intravenous Arm board
  • Padded Shoulder Supports Wristlets
  • A pair of knee crutches
  • Footrest with SS top.
  • Lateral Side Supports
  • Kidney Bridge
  • Water proof Rubber Mattress



Optional Accessories At Extra Cost :

  • S.S. Tray with bracket for Instruments.
  • Permeable Tops for X-Ray Cassettes.
  • Neuro Surgery accessories.
  • Ortho Attachment.

Technical Data

Technical Data
Intensity
Length of the table top
: 180 to 195 cms
Width of the table top
: 50 cm.
Minimum height
: 75 +/- 5 cms.
Maximum height
: 95+5 cm.
Hydraulic Lift
: 0 cms.
Lateral Tilt
: 20° +/- 20°
Flex
: 90°
Reflex
: 220°
Longitudinal Tilt
45° +/- 3°

Product Brochure

Product Brochure Link here
