Semi-Automatic Microtome (New Modular Design) SMI-325S4

Home ≫ Histopathology >Microtomes > Semi-Automatic Microtome (New Modular Design) SMI-325S4

Semi-Automatic Microtome (New Modular Design) SMI-325S4

Description

The Jindal semi automatic microtome characterizes a great combination of cost-effective competence and user comfort. Semi Automatic microtome is the instrument of choice for clinical histology and histopathology applications. Microtome has vertical and horizontal guidance by zero-backlash & maintenance free cross roller bearings. Microtome has stepper motor driven specimen feed and electronic coarse feed wheel. Microtome provide premium quality paraffin sections with easy smooth and noise free operation of hand wheel for high stability & precision.

These are used to produce thin sections of specimens of different hardness in both routine and research applications in biology, medicine and industry.

Manual sectioning is enhanced by the high precision motorized specimen feed for cutting paraffin as well as epoxy resin blocks which provides efficient and rapid Specimen exchange by using user programmable position.

Wide Antistatic Section Waste Tray:

The Wide antistatic section waste tray consistently gathers sectioning wreckage.

Universal Knife Holder:

The complete width of the knife can be used by using straight forward blade fastening mechanism. Using the entire knife edge is cost effective, particularly in laboratories with high specimen throughput.

Enquire Now

Detailed Images

Well Located Storage Area:

An incorporated storage tray makes sure that certain subsidiary tools are in hand at all times.

Safety During Sectioning:

Protection is assured by incorporated safety finger protection guard of the knife holder that exceptionally safe guards the blade edge. When used correctly the integrated finger protection guard rules out potential injuries because it can even remain on the blade edge during sectioning.

User Friendly Operation:

Section thickness setting mode by rotary knob. Microtome consist integrated lockable hand wheel capable of being locked in any desired position.

Range Of Section Thickness

0.5μm to 100μm

from 0.5μm – 5μm

in 0.5μm increment

from 5μm – 10μm

in 1μm increment

from 10μm -60μm

in 2μm increment

from 60μm – 100μm

in 5μm increment



Range Of Trimming Thickness

5μm to 500μm

From 5μm – 10μm

in 1μm increment

from 10μm 50μm

in 2μm increment

from 50μm – 500μm

in 5μm increment

Product Specifications

Section Thickness Indication

Bright LCD

Operating Temperature

10℃ to 40℃

Horizontal Specimen feed

24mm by stepper motor

Vertical Stroke Length

70mm

Forward & backward speed

Slow: 300µm/sec ; Fast : 900µm/sec

Specimen orientation

Horizontal 8°, Vertical 8°

Maximum Specimen Size (LXHXW)

55mmX60mmX40mm

Operating Voltage

220V Single Phase AC supply (Model with 110V also available)

 Retraction Value Range

5-50µm if programmable or fixed at a value within the above range

Weight

30Kg

Additional Feature

A wireless remote having keys for the operator to set the various parameters easily.

At a Glance

  • Blade holder remain stationary in all conditions for proper sectioning
  • Integrated lockable hand wheel capable of being locked in any desired position
  • Precise specimen orientation with zero-point indication with an orientable up to 8° X-Y axis to help in making perfect orientation
  • Manual sectioning with full hand-wheel rotation
  • Motorized horizontal specimen head movement can be done either using the feed buttons on the control panel (continuous or in step feeding mode) or using an ergonomically positioned coarse feed wheel.
  • Section counter and section thickness totalizer on the microtome
  • Each change in the sense of rotation electronically detected and automatically converted into an advance or retraction movement of the specimen without compromising the ribboning of the sections.
  • Universal cassette clamp (tissue microarray compatible) with both vertical and horizontal cassette holding capacity
  • Adjustable electronic coarse feed speeds for slow and fast forward and backward speed
  • All-important controls located on the user-friendly separate control panel with adjustable inclination angle for ergonomic operation
  • Specimen retraction occur in return stroke
  • Rocking mode function on the control panel for rapid trimming allows turning the hand-wheel back and forth over a short distance
  • Vibration free
  • Two manual sectioning modes rocking and conventional
  • Section thickness settings for trimming and sectioning can be selected and saved independently of each other
  • Personalized by user and selectable in preferred turn direction
  • Independent hand wheel locking systems
  • Universal cassette clamp (tissue microarray compatible) with both vertical and horizontal cassette holding capacity (2 Nos.)
  • Blade Holder for both high- and low-profile disposable steel blades with integrated finger guard protection covering both the top and sides of the blade
  • Unique magnetized antistatic section waste tray holds a large volume of waste and offers ease of cleaning due to its antistatic surface resulting in improved workflow and efficiency at a reduced cleaning time.

Additional Accessories

  • Disposable blades high profile (30 pkt.)
