Shaking Water Bath SMI-SWB-06-1
CLICK TO SCAN
Description
A shaking water bath is a biochemical instrument that combines a temperature-controlled constant-temperature water bath with an oscillator. This series of instruments uses an advanced PID adaptive control algorithm to regulate both temperature and oscillation frequency. The built-in stainless steel body features a formed groove, and the heating tube is made of special stainless steel, ensuring uniform heating, corrosion resistance, and low heat loss. It is used for water bath constant-temperature heating, oscillation, and other temperature-controlled experiments. This instrument is an essential tool for biology, environmental protection, medicine, healthcare, education, and scientific research.
Features
Built-in over-temperature protection ensures safe and reliable operation.
DC brushless motor drive ensures low noise, maintenance-free operation, and long service life.
Compact and innovative design maximizes the number of experimental samples while occupying minimal space.
- The shaking water tank is made of high-quality 304 stainless steel with an integrated molded design, offering excellent corrosion resistance.
User-friendly man-machine interface displays all operating information in real time, allowing convenient monitoring of the equipment’s status.
The tank features a unique internal sealing structure to prevent water leakage. An independent side drain makes cleaning the inner tank after use simple and convenient.
Equipped with a microcomputer-controlled PID adaptive algorithm, it provides automatic temperature control with uniform heating and high precision.
The special stainless steel heating tube provides uniform heating, corrosion resistance, and low heat loss. A variety of tray options are available to suit different experimental needs.
The oscillation and heating systems are independently designed. When oscillation is not needed, the unit can function as a constant-temperature water bath, offering dual functionality in one machine.
Technical Data
Model | SMI-SWB-06-1 |
| Speed | 30-300rpm/min |
Amplitude | 20mm(16/26 optional) |
Temp. Range | RT+5-100℃ |
Time accuracy | ±0.5℃ |
Shaking Mode | Orbital |
Voltage | AC220V/110V |
Size | 510 X 370 X 350 mm |
| Net Weight | 14kg |
