Cryostat Microtome (Double Compressor) SMI-3010D

The JINDAL Cryostat Microtome is designed for sectioning natural tissues. These are specially designed for clinical and research operations. Sections have the high resolution of cytological details required for pathological diagnosis, histochemistry, fluorescence, biochemistry, microscopy, etc. Technologies are simple and easy to learn.

The unique dual compressor cryostat is equipped with a double cooling circuit, which allows specimen cooling separate from the cryo chamber and the freezing shelf. The user can set the temperature of the specimen independently from the cryochamber.

The unique dual compressor cryostat is equipped with a double cooling circuit, which allows specimen cooling separate from the cryo chamber and the freezing shelf. The user can set the temperature of the specimen independently from the cryochamber.

Features

  • Large, spacious stainless steel cryo chamber.
  • Antimicrobial powder coating with galvanized steel sheet construction.
  • Motorized specimen feed is coarse advance with specimen retraction.
  • CFC-free refrigerant with a noiseless compressor to achieve low temperatures up to -35°C.
  • Heated sliding glass door to prevent condensation.
  • microprocessor-based touch-screen operation.
  • Automatic and manual hot gas defrosting
  • Easy selection from cutting to trimming by touch of a button
  • Adjustable cutting angle.
  • Mounted on castors for easy movement.
  • UV sterilization, which can be activated by the touch of a button,
  • Ergonomic design blade holder with finger guard for safety and anti-roll device
  • Enclosed drainage system.
  • Encapsulated splash-protected microtome
  • user-friendly menu with a section counter.
  • Separate compressor for specimen cooling up to -35°C.
  • LED illumination for the cryochamber
Previous
Next
Enquire Now

Modular Design Control System

  • Chromatic LCD touch screen for user-friendly operation.
  • Hibernate automatically or manually and wake up in 15 minutes.
  • UV sterilization at the touch of a button
  • Peltier cooling station for quick freezing of specimens
  • Section thickness totalizer with section counter
  • Slow and fast speeds of specimen feed forward and reverse.

Microtome

  • Smooth and light handwheel with locking device lever.
  • X-Y-Z 8° specimen orientation is triaxially adjustable.
  • Precise, durable roller guides made in Germany ensure easy sectioning of hard tissue samples and smooth movement.
  • Adjustable retraction and can be turned off.

Cryo Chamber

  • Large spacious stainless steel chamber with large freezing shelf to hold up to 20 specimen discs.
  • With waste tray & instrument rack.
  • Heat Extractor in quick freeze shelf.

Disposable Blade Holder

  • Designed to use both High & low profile blades.
  • An anti-fatigue cam lock ensures blades clamp tight.
  • The blade holder can move laterally for safety & to ensure full use of the blade.
  • Glass anti roll device to adjust the angle & gap with the pressure plate.
  • Steel push rod to eject the blade.
Range of Trimming Thickness
0µm – 20µm
In increment of 2µm
20µm - 50µm
In increment of 5µm
50µm – 100µm
In increment of 10µm
1000µm – 500µm
In increment of 50µm
Range Of Section Thickness
0.5µm – 1µm
In increment of 0.5µm
1µm - 10µm
In increment of 1µm
10µm – 20µm
In increment of 2µm
20µm – 50µm
In increment of 5µm
50µm – 100µm
In increment of 10µm

Technical Data

Product
Cryostat Microtome (Double Compressor)
Model No.
SMI-3010D
Temperature of Cryo Chamber
Adjustable Up to -35°C
Temperature of Specimen
Up to -35°C
Temperature of Quick Freeze Shelf
Up to -45ᵒC
Number of Freezing Stations
20
Number of Peltier Cooled Freeze Stations
Up to -60ᵒC:2
Motorized Coarse Feed
Slow 600um/sec ; Rapid 900um/sec
Total Specimen feed
28mm
Vertical Stroke
60mm
Maximum Specimen Size
55 X 55mm
Refrigeration Capacity
690W x 2
Refrigerant
R404A ; 300g±5g
Input Power
1300 VA
Net weight
200Kg
Designed to Operate On
220V/50Hz AC Supply or 110V/60Hz AC Supply
Defrost
1 automatic defrost cycle per 24hr/manual(duration 12 minutes)
Dimensions of the Machine
780mmL (705mm without handwheel) X 700mmW X 1152mmH
