CO2 Incubator – Carbon Dioxide Incubator SMI-132

Home Co2 Incubator>CO2 Incubator – Carbon Dioxide Incubator SMI-132



CO2 Incubator – Carbon Dioxide Incubator SMI-132

CLICK TO SCAN

Description

JINDAL CO₂ Incubator provides a perfectly stabilized and sterilized environment for Cell Culture and study of temperature / CO₂ on human tissues. The incubator incorporates SS 304 Construction and Copper enriched stainless steel alloy interior surfaces to eliminate contamination sources, mitigate the effects of airborne contaminants introduced through normal use and provides high degree of Germicidal Protection. Laboratories and medical professionals, world over, rely on our CO₂ Incubators.

Jindal’s CO₂ Incubator uses Direct Heat / Air Jacketed Heating System which surrounds the inner chamber walls combined with natural convection airflow that radiate wall heat through thermal conduction. This technique achieves accurate, uniform and highly responsive temperature control within the chamber.

The Dual Beam Infrared CO₂ system is linked to a microprocessor controller with a sophisticated PID algorithm. This ensures Ultra-Fast recovery without overshoot and accurate CO₂ averages even with frequent access with multiple door openings.

All instruments functions including the temperature, CO₂ % and Humidity % of the incubator are programmable with a facility for a selectable alarm for each parameter. The easy to read 4 lines Liquid Crystal Display (LCD) with all set and process temperature, CO₂ % and Humidity % and visual alarm for each parameter provides stabilized and accurate controls.

Optional Ultra Protection Systems:-

The Jindal CO₂ incubator (Carbon Dioxide Incubator) also comes with a programmable Ultraviolet Lamp, isolated from cell cultures, that sterilizes conditioned air and humidity water reservoirs to avoid contamination without disturbing cell cultures in vitro.

Rapid Response “Class 100 product” affects the Yields and Reliability by airborne contamination costing valuable time and money. Class 100 HEPA Filter Flow System air quality provides an ideal culturing environment.

At a Glance:-

  • Compact, Ergonomic model
  • Direct Heat / Air Jacketed Temperature Control
  • SS enriched Contamination resistant interiors
  • UV protection for Contamination control
  • Precise P.I.D. Enhanced CO₂ recovery
  • High performance Control, Monitoring and Alarm Functions
  • Dual beam InfraRed CO₂ sensor
  • Menu driven through microprocessor
  • User friendly software
  • Password Protection for safety
  • User selectable single/profile control mode
  • In built Real Time Clock
  • Date Retentive Timer for both UV and process

Specifications:-

Std. Shelves: 3 Nos. [Maximum 16 Nos.] Removable inner chamber plenum, shelves and rails

Utility Connections:-

Gas Connections: 1/4″ [6.3 mm] tubing connections

Gas Input Pressure:-

20 PSIG[1.4BAR] : Two stage gas regulator required

Performance Specifications:-

  • Temperature Range: 5°C above ambient up to 55°C
  • Temperature Uniformity: ± 0.5°C at 37°C
  • Temperature Accuracy: ± 0.5°C
  • CO₂ Range: O to 20%
  • CO₂ Resolution: 0.1%
  • Temperature Recovery: 0.15°C/minute

Electrical Requirements:-

  • 220 V AC, 50 Hz.
  • Single phase (Model with 110V also available)
  • Startup Power: 130 Watts.
  • Running power at 37°C: 75 Watts

Standard Features:-

  • InfraRed CO₂ gas sensor
  • Microcomputer-based control
  • Full size 17″ x 12″ water pan
  • 3 polished SS shelves
  • Remote alarm contacts
  • Precision Integrated Circuit
  • Temperature sensor
  • Replaceable fan wheel
  • Tempered inner glass door
  • Eight-foot [2.5 m] power cord
  • Spool type gas solenoid valve
  • CRL cross-links high density
  • Chamber wall insulation
  • All silicon tubing

Optional Accessories:-

  • Automatic Internal Tank Switch
  •  RS-232 Communication Output
  •  Additional Shelves
  •  External CO₂ Tank Alarm
  •  External Tank Switch
  •  Surge Protector
  •  3 Inner Lexan Doors
  •  Replaceable HEPA filter
  •  Hot air sterilization
  •  UPS system
  •  Heavy duty leg levellers
  •  Touch screen control
  •  Mobile phone alert system

Chamber Capacity Available:-

  • 100 litres
  •  200 litres
  •  300 litres
  •  450 litres

Other chamber capacities can also be designed as per customer’s requirement
