Hand Dryer SMI-HD-01

Home ≫ Clean Air>Hand Dryer SMI-HD-01

Hand Dryer SMI-HD-01

CLICK TO SCAN

Description

  • Clean Hand Dryer is common equipment, which is generally installed in the entrance of the clean room or biological lab with washbasin,
  • In order to clean and dry hands by clean air filtered by HEPA filter.
  •  It has the function of washing and drying hands that the air blew out is sterilized and filtered by HEPA filter.
  •  The air velocity is 100m/s that can dry hands in short time.
  •  Manual touchable switch, along with inducted switch, enhance the flexibility and reliability.
  • Washing and drying time can be adjusted by touchable control panel.
  •  It can adopt SS or Steel Sheet with lacquer according to the user’s requirement.

Technical Data

Model/Item
SMI-HD-01
SMI-HD-02
SMI-HD-03
Filter Efficiency
≥99.99%(@≥0.5μm)
≥99.99%(@≥0.3μm)
Air Velocity
95 m/s
80~100 m/s
Rated Power
6 w
1.4 w
Power Supply
AC220V, 1Φ, 50Hz
Washing/Drying Time
0~99s(Adjustable)
Overall Dim. (WXHXD)
1480X530X940 mm (58.3''x20.9''x37.0'')
400X850X310 mm (15.7''x33.5''x12.2'')
634X1100X470 mm (25.0''x43.3''x18.5'')
Diameter of Water Pipe (in)
1/2”
-
1/2”
Diameter of Water Pipe (out)
Φ32
1/2”
Φ32
No. of Operator
3
1
1
Material Science
SUS304
SPCC
SPCC
