Class II Type A2 Biological Safety Cabinet SMI-163A4

CLICK TO SCAN

Description

JINDAL Biological Safety Cabinet Class II type A2 that provides personnel product and environmental protection from hazardous particles. The safety cabinet offers a high level of HEPA/ULPA filter efficiency of 99.995% efficiency between 0.1 to 0.3 microns & an airflow pattern of 70% air recirculation and 30% exhaust. Stand height is 28 inches.

The Exterior body is made of SPCC duly epoxy powder coated material. The work zone is made of stainless steel 304(AISI304) with removable facility for easy cleaning and decontamination and front service access panel for comfortable maintenance. The side wall made of stainless steel 304 grade material.

The Cabinet is equipped with a smart, safe and user-friendly digital display system that protects the operator and provides alerts for periodic maintenance actions and parts’ replacement. The cabinet has safety reasons for the user & the environment and accessories is supplied with each cabinet Foot operated burner, canopy to connect external duct.

The cabinet is precisely control ventilation to sweep airborne particles produced during routine microbiological procedures way from the user while maintaining a controlled environment for the specimen. The Bio safety cabinet has consistent and reliable down flow velocity across the supply HEPA filter over the life of the cabinet. The cabinet has a pressure sensor for detect pressure drop across the supply filter rather than at just one point across the down flow. Pressure sensor encased to protect the sensor from temperature, humidity and other environmental phenomena that impact the sensor’s performance. The cabinet has stable and self-compensating airflow, despite building voltage fluctuations & filter loading.

The system also has a programmable “standby” mode that shuts down all unnecessary electricity consumption and sets vital components at the required safety level. The safety cabinet has dual DC motors automatically adjust the airflow speed without the use of a damper to ensure continuous safe working conditions even without maintenance adjustments.

Transparent toughened sash with conventional weight counter balance system.



Detailed Images

Advantages

  • EN12469 certified
  • H14 as per EN-1822 certified HEPA Filter
  • Dual stage filtration system
  • Low heat & low energy consumption
  • Standby mode to economize power consumption
  • Economy mode of operation to reduce energy consumption
  • Vertical airflow direction
  • Class 2 air cleanliness class as per ISO 14644-1
  • Integrated digital microprocessor control system with graphic LED display and button with indication light
  • Magnehelic gauge digital type low- and high-pressure indicator
  • Closing/opening of front door integrated with the UV light ON/OFF
  • Display of life of HEPA filter and UV lamp
  • UV lamp cut off in case the fluorescent lamp light is turned on and over current cut off
  • Audio visual alarms for any malfunction of the parameters set
  • Digital display and control panel outside the cabinet with hour counter
  • Fan on/off and adjustable
  • Germicidal UV & white LED/Tubes
  • Front panel of the cabinet concave for enhancing user comfort
  • UV light programmable to allow for specific exposure times from 0 to 24 hours
  • LED lamp on/off, UV lamp on/off with adjustable UV sterilization timer
  • Total replacement alarm
  • Auto speed increase on the opening door for maintaining velocity
  • Automatic component features that adjust blower speed to maintain the optimum airflow in case of filter loading
  • Silent fan blower with noiseless and vibration free working environment
  • 4 Nos. of castor wheels with lock for easy movement
  • Universal gas valve/port inside the cabinet
  • Drain pan made of stainless steel and spill trough with drain valve
  • Designed to operate at 220-240V,50Hz with single phase power supply

Additional Accessories

  • HEPA filter
  • Gas burner
  • Two access points
  • Stand with castors & break
  • Ergonomic arm rest

Technical Data

Specs/Model

SMI-163A3

SMI-163A4

SMI-163A6

External Size (W X D X H)

1030 X 850 X 2100mm

1500 X 850 X 2100mm

1870 X 850 X 2100mm

Internal Size (W X D X H)

900 X 600 X 600 mm

1200 X 600 X 600 mm

1700 X 600 X 600mm

Working Area Height

750mm

750mm

750mm

Maximum Front Sash Opening

520mm

520mm

520mm

Front Sash Opening

200mm

200mm

200mm

Production/ Test Standard

CE / In accordance with EN12469

CE / In accordance with EN12469

CE / In accordance with EN12469

Air Flow Volume (Inflow)

417 CFM

417 CFM

417 CFM

Air Flow Volume (Downflow)

663 CFM

663 CFM

663 CFM

Air Flow Volume (Exhaust)

459 CFM

459 CFM

459 CFM

Downflow Velocity

0.35m/s, 60FPM

0.35m/s, 60FPM

0.35m/s, 60FPM

Inflow Velocity

0.53m/s, 105FPM

0.53m/s, 105FPM

0.53m/s, 105FPM

Front Window



Laminated toughened glass

≥ 5mm anti UV

Laminated toughened glass

≥ 5mm anti UV

Laminated toughened glass

 ≥ 5mm anti UV

Filter

HEPA/ULPA filter efficiency of 99.995% efficiency between 0.1 to 0.3 microns

HEPA/ULPA filter efficiency of 99.995% efficiency between 0.1 to 0.3 microns

HEPA/ULPA filter efficiency of 99.995% efficiency between 0.1 to 0.3 microns

Noise Level

60 dB

60 dB

60 dB

White Fluorescent light illumination

1200Lux Eco-friendly

1200Lux Eco-friendly

1200Lux Eco-friendly

Display

 LED Display

LED Display

LED Display

Power Sockets

Two (15/5 Amp)

Two (15/5 Amp)

Two (15/5 Amp)

UV Light

20W ; 254nm

20W ; 254nm

20W ; 254nm

Audio-Visual Alarms

Deviation in airflow velocity,

Filter replacement, sash

position, UV life timer, blower failure, window position

Deviation in airflow velocity,

Filter replacement, sash

position, UV life timer, blower failure, window position

Deviation in airflow velocity,

Filter replacement, sash

position, UV life timer, blower failure, window position

Taps

Water Tap : 1

Gas Tap : 1

Vacuum/Air Tap : 1

Water Tap : 1

Gas Tap : 1

Vacuum/Air Tap : 1

Water Tap : 1

Gas Tap : 1

Vacuum/Air Tap : 1

Weight

316Kg

371Kg

390Kg
