Class II Type A2 Biological Safety Cabinet SMI-163A

Home Clean Air >Biosafety Cabinets >Class II Type A2 Biological Safety Cabinet SMI-163A

Class II Type A2 Biological Safety Cabinet SMI-163A

CLICK TO SCAN

Description

JINDAL Biological Safety Cabinet Class II type A2 is vertical designed with freestanding model stand with castors to protect the lab staff, the environment and sensitive work processes in which biological agents are used. The safety cabinet offers a high level of contamination protection, based on two advanced HEPA/ULPA operating at an efficiency of 99.995% with a particle count of 0.3 μm & an airflow pattern of 70% recirculation and 30% exhaust. Stand height is 28 inch.

The Cabinet consist work bench construction with 1.5mm Stainless steel 304 16-gauge material. The Cabinet outer body is made of 1.2mm EG steel 18 gauge with epoxy-polyester anti-microbial powder coating material. The interior of the cabinet including the work area and side panels and back panel are made of stainless steel 304G  4B finish material. Gas and vacuum fixtures on side panels and 15 amp plug socket on back panel.

The Cabinet is equipped with a smart, safe and user-friendly color touch-screen control system that protects the operator and provides alerts for periodic maintenance actions and parts’ replacement. The cabinet has safety reasons for the user & the environment and accessories is supplied with each cabinet Foot operated burner, canopy to connect external duct.



The cabinet is preserved for safety reasons for the user and the environment. The BIO safety cabinet has consistent and reliable down flow velocity across the supply HEPA filter over the life of the cabinet. The cabinet has a pressure sensor for detect pressure drop across the supply filter, rather than at just one point across the down flow. Pressure sensor encased to protect the sensor from temperature, humidity and other environmental phenomena that impact the sensor’s performance.

The system also has a programmable “standby” mode that shuts down all unnecessary electricity consumption and sets vital components at the required safety level. The safety cabinet has automatically dual DC blower for airflow speed without the use of a damper to ensure continuous safe working conditions, even without maintenance adjustments. Transparent toughened safety glass sash with Conventional weight counter balance system.

Detailed Images

Advantages

  • EN12469 certified
  • EN-1822 certified HEPA Filter
  • Power consumption 250W
  • Dual stage filtration system
  • Plenum silver-ion impregnated antimicrobial powder coating material
  • With memory function in case of power failure
  • Standby mode to economize power consumption
  • Economy mode of operation to reduce energy consumption
  • Vertical airflow direction
  • Display for displayed real time perimeters of air inflow and down flow, filter life, sash opening
  • Pressure monitoring system with pressure drop separate sensors to measure pressure
  • ISO 10/Class 100 cleanliness level according to ISO 14644-1.
  • Baffles airflow both towards on front and back end of the cabinet
  • Advanced air pressure sensing technology
  • HEPA Filter is made with Media Ultra clean glass fibre paper imported.
  • On-screen control buttons and audio-visual alarms
  • Change downflow and exhaust HEPA filters to accurate measurement of both airflow
  • Port provision for clean and safe routing for vacuum tubing
  • Microprocessor control system
  • Data transfer directly to LAN interface
  • Dynamically and statically balanced aluminium centrifugal impeller blower driven by Single phase motor enclosed in PU coated GI casing directly mounted type.
  • Programmable UV light allow for specific exposure times from 0 to 24 hours.
  • Internal fluorescent lighting Fixture such that the light is not facing the user and is out of the air stream.
  • Automatic air flow compensation technology with real-time filter
  • Use programmable UV germicidal tube
  • Double layered, laminated vertical sliding front sash (UV protected glass)
  • Air vent to prevent accidental blockage
  • Control Panel and Performance monitor display inflow / downflow velocities, hours of use to verify proper cabinet operation
  • RS – 232 port system available
  • All interior and exterior parts are painted and smooth to ensure no risk of cuts.
  • Window design easily lowers cleaning of inner surfaces protect users by maintaining inflow, even when the window is lowered.
  • Drain pan negatively pressurized to ensure that any contaminants are quickly trapped and pushed into the HEPA filters
  • Work on 220-240V, Single Phase 50Hz power supply

Accessories

  • Voltage Stabilizer
  • Arm set
  • Fixed/adjustable stand
  • UPS with backup
  • Magnehelic Gauge
  • Extra HEPA Filter

Technical Data

Specs/Model

SMI-163A

SMI-163A

SMI-163A

External Size (WXDXH)

850 X 750 X 2130 mm

1360 X 750 X 2130 mm

1870 X 750 X 2130 mm

Internal Size (WXDXH)

900 X 600 X 600 mm

1210 X 600 X 600 mm

1690 X 600 X 600 mm

Working Area Height

500 mm

500 mm

500 mm

Maximum Front Sash Opening

520 mm

520 mm

520 mm

Tested Front Sash Opening

254 mm

254 mm

254 mm

Production/Test Standard

CE / In accordance with EN12469

CE / In accordance with EN12469

CE / In accordance with EN12469

Air Flow Volume(Inflow)

350 CFM

350 CFM

350 CFM

Air Flow Volume(Downflow)

400 CFM

400 CFM

400 CFM

Downflow Velocity

0.40m/s, 60FPM

0.40m/s, 60FPM

0.40m/s, 60FPM

Inflow Velocity

0.5m/s, 100 FPM

0.5m/s, 100 FPM

0.5m/s, 100 FPM

Air Flow Volume

(Exhaust )

250 CFM

250 CFM

250 CFM

Front Window 10” sash open

5mm thick toughened sheet

5mm thick toughened sheet

5mm thick toughened sheet

Filter

HEPA/ULPA Two, 99.995% efficiency at a particle count of 0.3µm, with pressure drop of 14 mm WG

HEPA/ULPA Two, 99.995% efficiency at a particle count of 0.3µm, with pressure drop of 14 mm WG

HEPA/ULPA Two, 99.995% efficiency at a particle count of 0.3µm, with pressure drop of 14 mm WG

Noise Level

5454

54

Illumination

>900Lux Eco-friendly

>900Lux Eco-friendly

>900Lux Eco-friendly

Display

LED Display with Pressure Gauge Differential

LED Display with Pressure Gauge Differential

LED Display with Pressure Gauge Differential

Power Sockets

Two (15/5 Amp)

Two (15/5 Amp)

Two (15/5 Amp)

Taps

Water Tap : 1

Gas Tap : 1

Vacuum/Air Tap : 1

Water Tap : 1

Gas Tap : 1

Vacuum/Air Tap : 1

Water Tap : 1

Gas Tap : 1

Vacuum/Air Tap : 1

Audio-Visual

Alarms

Deviation in airflow velocity, Filter replacement, sash position, UV life timer

Deviation in airflow velocity, Filter replacement, sash position, UV life timer

Deviation in airflow velocity, Filter replacement, sash position, UV life timer

Weight

316 Kg

350 Kg

370 Kg

UV Light

30W ; 254nm

30W ; 254nm

30W ; 254nm
