Air Curtain SMI-4012AC

Air Curtain SMI-4012AC

CLICK TO SCAN

Description

  • Air Curtain is supporting equipment for a clean room and workshop. It can form a curtain of air flow to prevent insects from entering and remove the dust adhering of the operator and goods into the working area and can be used in the industries of food,pharmacy, cosmetics etc.
  • Unbalanced cross high speed air flow on both sides can effectively prevent insects from entering.
  • It adopts an adjustable fan that can realize frequency control on both sides.
  • It has small floor space and low power consumption.
  • The layout can be adjusted by changing the position of the high speed and low speed side according to environmental conditions.
  • It can be interlocked with the sliding door.
  • It can be specially designed by the environmental conditions.

Technical Data

Model No.
AAC-20250CAAC-20250C
Insect proof Efficiency
~95%
Air Volume
~260 m3/min (9182 cfm)
Air Velocity
High air velocity side: 20~24 m/s (3936~4723 fpm)
Low air velocity side: 13~15 m/s (2558~2952 fpm)
Power Supply
AC380V, 3φ, 50Hz
Rated Power
4.5 kw
Body
High grade steel with ivory color static powder coating
Overall Dim. (WXDXH)
3000X850X2600 mm (118”x33.5”x102.4”)
Dim. of Showering Area (W1XD1XH1)
2000X500X2500 mm (78.7”x19.7”x98.4”)
