Miniature High-speed Centrifuge SMI-MC-15

Home ≫Centrifuges> Miniature High-speed Centrifuge SMI-MC-15

Miniature High-speed Centrifuge SMI-MC-15

CLICK TO SCAN

Description

JINDAL Miniature High-speed Centrifuge has a compact design with high rotor speed and low noise. It is elegant and small with a variable frequency motor, SMI-MC-15 has excellent acceleration to achieve target speed / stop to save time.

Features

  • Compact and small footprint size, saves space
  • Variable frequency motor for excellent acceleration. High speed with low noise
  • To achieve max. Speed 15000rpm (1500 xg) or stop from max. speed, it takes about 15s
  • Bright LCD displays speed and time
  • Rotor is made of aluminum alloy, chemical resistant, accepts dry heat sterilization
  • Short Key makes “touch to operate” easy and convenient
  • Excellent fluid air exchange technology. The unique three air flues design lowers the rising temperature. Protects temperature sensitive samples
  • Self-locking function, Press the key to open the cover after operation. Safe and reliable
  • Aluminum rotor and plastic rotor for optional. Aluminum rotor can bear heat disinfection
  • Plastic acceleration speed is faster than aluminum rotor
Enquire Now

Technical Data:

Product
Miniature High-speed Centrifuge
Model
SMI-MC-15
Speed Range
100 ~15000rpm (increment: 100rpm)
Max. RCF
15000 xg
Max. Sample Capacity
2 mL/1.5mL x 12
Time Range
20 sec ~99 min
Acceleration to Max. Speed
around 15s
Deceleration to stop
around 15s
Safety
Self-lock, over-speed, over-temp., status diagnosis system
Other Functions
Speed/RCF switch, touch operation, operating status display, alert
Voltage
AC 220-230V / AC 110-120V, 50/60Hz
Power
105W
Fuse
250V, 1A, Ф5x20
Dimension (W x D xH)mm
220mm W x 240mm D x 145mm H
Net Weight
5.1Kg
