Large Capacity Refrigerated Centrifuge SMI-154-7M-CDL7M

Home ≫Centrifuges> Large Capacity Refrigerated Centrifuge SMI-154-7M-CDL7M

Large Capacity Refrigerated Centrifuge SMI-154-7M-CDL7M

CLICK TO SCAN

Description

JINDAL Large Capacity Refrigerated Centrifuge is designed to meet the requirements of the laboratory.This Centrifuge finds its extensive use in the field of blood station, pharmaceutical factory, biochemistry, biological products and so on. Its max volume is 12 liters,it is the ideal instrument for blood separation, protein precipitation and cell collection.

Features:

  • Brushless frequency motor in great motor, free maintenance, no powder pollution, quick in speed up and down
  • Flexible axle driven system which drive the rotor directly, smooth in operation, low noise and small vibration
  • Imported compressors fluorine free, double cycle cooling, cold and hot alternating easily, free environment pollution and precise in temperature control
  • Microprocessor control, digital display indicates the speed, time, RCF in operation, speed rising and reducing quick, operate simply
  • 10 kinds of program stored in the memory, 10 kinds of accelerating and decelerating
  • Automatically electric lid lock, super speed, over temperature protection and imbalance protection. The centrifuge body is made of high quality steel, safe and reliable
  • 3 tiers protection steel cover, safe and reliable
Enquire Now

Technical Data:

Product
Large Capacity Refrigerated Centrifuge
Model No
SMI-154-7M-CDL7M
Max Speed
7000r/min
Max RCF
11900*g
Time Range
1~99H59min
Speed Accuracy
±50r/min
Weight
380Kg
Dimension
950*870*1300mm
Packaged Weight
420Kg
Packaged Dimension
1150*1050*1405mm
Capacity
6*2400mL
Noise
≦65dBA
Power
AC110/220V, 50-60Hz,35A
Rotor Identification
Automatic Identification
Temperature Range
-20~40℃
Temperature Accuracy
±1℃
Package
Wooden Box

Matched Rotors: (Rotors to be ordered separately from the machine)

Rotor No.
Rotor Type
Speed (rpm)
Capacity
RCF(*g)
No.30324
Fixed Rotor
7000 rpm
6*1000mL
11900
No.30399
Swing Rotor
4000 rpm
6*2000mL
5600
