High Speed Refrigerated Micro Centrifuge SMI-154-16E-TGL16E

Home ≫Centrifuges> High Speed Refrigerated Micro Centrifuge SMI-154-16E-TGL16E

High Speed Refrigerated Micro Centrifuge SMI-154-16E-TGL16E

CLICK TO SCAN

Description

JINDAL High Speed Refrigerated Micro Centrifuge is designed to meet the requirements of the laboratory.

Features

  • Brushless DC motor, no carbon dust pollution, unnecessary to maintain, quick in speed up and down
  • Microprocessor control, digital display indicates the speed, time, RCF in operation, running parameters can be edited
  • Imported compressors fluorine free, double cycle cooling, cold and hot alternating easily, free environment pollution and precise in temperature control
  • Automatically electric lid lock, super speed, over temperature protection and imbalance protection. The centrifuge body is made of high quality steel, safe and reliable
  • Rotor is connected to spindle by specialized taper sleeve, loading simple and quick, no direction
  • 3 tiers protection steel cover, safe and reliable
Enquire Now

Technical Data

Product
High Speed Refrigerated Micro Centrifuge
Model No
SMI-154-16E-TGL16E
Max Speed
16000 rpm
Max RCF
19040*g
Capacity
10*5mL
Noise
≦55dBA
Time Range
1~99H59min
Weight
43Kg
Dimension(DxWxH)mm
508*450*270mm
Power supply
AC110/220V, 50-60Hz,5A
Speed Accuracy
±50r/min
Temperature Range
-20~40℃
Packaged Dimension
658*600*370mm
Packaged Weight
53Kg
Rotor Identification
Automatic Identification
Temperature Accuracy
±1℃

Matched Rotors: (Rotors to be ordered separately from the machine)

Order No.
Rotors No
Max Speed r/min
Volume(mL)
Max RCF(g）
31001
Angle Rotor
16000
40*0.2mL
19040
31002
Angle Rotor
16000
24*0.5mL
18480
31003
Angle Rotor
16000
12*1.5/2mL
16260
31004
Angle Rotor
16000
10*5mL
17880
31005
Angle Rotor
14000
20*1.5/2
15580

Product Brochure

Product Brochure Link here
