The Jindal Centrifuge SMI-154BTHS-03 is equipped with 15 rotors and various adapters. Among these, the 6×50 ml (round/conical) rotors are widely used. The unit supports both a high-speed rotor (18,500 rpm) and a high-capacity rotor (4×100 ml).
A special wind deflector helps maintain sample integrity, while the damping system reduces noise and ensures stable operation.
Equipped with a 7-inch full touch screen, offering a simple interface with all parameters visible at a glance. Features stepless speed adjustment and automatic conversion of centrifugal force, displayed on the same screen.
Multiple program memories allow users to save and name programs for convenient recall.
Automatic identification system for 15 magnetic rotors. Supports 12×1.5/2 ml angle rotor (max speed: 18,500 rpm) and 4×100 ml swing rotor (with different adapters available).
10 acceleration and 11 deceleration stages, with adjustable free parking time.
Multiple self-diagnostic protection functions, including safeguards against door interlock malfunction, over-speed operation, motor overheating, misoperation, and communication faults, ensuring user safety.
Model | SMI-154BTHS-03 |
Max. Speed | 18500r/min |
Max. RCF | 23797 x g |
Max. capacity | 4 X 100ml |
Speed accuracy | ±10r/min |
Time setting range | 1 s to 99min 59sec or 1 min to 99h 59 min |
Noise | ≤65dB (A) |
Power supply | AC220V±22V 50Hz |
Power consumption | 700W |
Dimension (W X D X H) | 380 X 505 X 360 (mm） |
Packing Dimension (W X D X W) | 480 X 780 X 460 (mm) |
Net Weight | 36kg |
Product Brochure Link here
