Under Counter Pharmacy Refrigerator 2℃ to 8℃ SMI-165UCPR-75L

Home ≫Ultra Low Temp. >Undercounter Pharmacy Refrigerators >Under Counter Pharmacy Refrigerator 2℃ to 8℃ SMI-165UCPR-75L

Under Counter Pharmacy Refrigerator 2℃ to 8℃ SMI-165UCPR-75L

CLICK TO SCAN

Overview

The Jindal 2C to 8℃ Undercounter Medical Refrigerator SMI-165UCPR-75L is a smart, compact unit designed with a modern, updated appearance. This small laboratory and medical refrigerator features a double-layer tempered glass door with anti-condensation and electric heating functions, ensuring excellent thermal insulation performance. The high-efficiency evaporator and advanced air-cooling system eliminate the risk of frosting, maintaining uniform and stable temperatures inside the cabinet. A comprehensive alarm system with multiple alerts ensures the safety of stored materials. This pharmaceutical refrigerator is ideal for use in hospitals, laboratories, pharmacies, health centers, pharmaceutical factories, disease control centers, medical facilities, and more.

Advance Control System

This 2℃ to 8℃ vaccine refrigerator features a highly precise temperature control system, allowing the temperature to be freely set within the 2℃ to 8℃ range. The high-brightness digital display accurately shows both temperature and humidity, ensuring precision up to 0.1℃.
Enquire Now

Refrigeration System

The Mini Medicine Refrigerator SMI-165UCPR-75L is equipped with an environmentally friendly, Freon-free refrigerant and a high-efficiency compressor, ensuring superior cooling performance and temperature uniformity. It operates with an air-cooling system and features an auto-defrost function.

Alarm System

It is equipped with a well-developed audible and visual alarm system, including sensor failure alarms, door open alarms, high-temperature/low-temperature alarms, and power failure alarms, ensuring safer storage. The compressor features turn-on delay protection, guaranteeing reliable operation.

Ergonomic Design

The under-counter refrigerator is designed with a lock to prevent unauthorized access. Its premium LED lighting system ensures full visibility inside the cabinet. The shelves are made of PVC-coated steel wire, making them easy to clean and maintain.

Scope of Application

The medical-grade benchtop or under-counter vaccine refrigerator is suitable for storing biological products, vaccines, drugs, reagents, and more. It is ideal for use in pharmacies, pharmaceutical factories, hospitals, centers for disease prevention and control, clinics, and similar facilities.

Features

  • The upright medical refrigerator allows precise temperature settings within the range of 2℃ to 8℃.
  • It is equipped with a high-quality, well-known Chinese brand compressor and patented fan motor for reliable performance.
  • The unit includes 2 to 3 adjustable high-quality steel wire shelves, allowing flexible height adjustment to meet various storage needs.
  • The interior is made of spray-coated aluminum panels, while the exterior features high-quality structural steel for durability.
  • The electrically heated glass door, filled with inert gas, provides excellent thermal insulation.
  • A cooling fan inside operates when the door is closed and stops when the door is opened to maintain temperature stability.
  • The CFC-free polyurethane foam insulation layer is environmentally friendly and highly efficient.
  • The refrigerator is also equipped with three temperature sensors.
  • If the primary sensor fails, the secondary sensor is automatically activated to maintain safe operation.
  • Standard features include a built-in USB data logger, remote alarm contact, and an RS485 interface for integration with a monitoring system.

Technical Data:



Model

SMI-165UCPR-75L

Capacity (L）

75

Internal Size (W X D X H)mm

444 X 440 X 536

External Size(W X D X H)mm

542 X 566 X 764

Package Size(W X D X H)mm

575 X 617 X 815

NW/GW(Kgs)

41/45(wood packing)

Temperature Range

2 to 8℃

Ambient Temperature

16-32℃

Cooling Performance

5℃

Climate Class

N

Controller

Microprocessor

Display

Digital display

Compressor

1 Nos.

Cooling Method

Forced air cooling

Defrost Mode

Automatic

Refrigerant

R600a

Insulation thickness(mm)

L/R:48,B:50

External Material

PCM

Inner Material

Aumlnum plate with spraying

Shelves

3 (coated steel wired shelf)

Door lock with key

Yes

Lighting

LED

Access Port

1pc. Ø 25 mm

Casters

2+2( leveling feet）

Data logging/Interval/Memory capacity

USB/Record every 10 minutes/1000,000data

Door with heater

Yes

Backup Battery

Yes

Temperature

High/Low temperature, High ambient temperature

Electrical

Power failure, Low battery

System

Sensor failure, Door ajar, Built-in datalogger USB Failure, Communication failure

Standard

RS485, Remote alarm contact
