Microprocessor Based Digital Disintegration Apparatus SMI-AYL-121

Home ≫Analytical Instruments>Microprocessor Based Digital Disintegration Apparatus SMI-AYL-121


Microprocessor Based Digital Disintegration Apparatus SMI-AYL-121


Product Description

Microprocessor Based Digital Disintegration Apparatus SMI-AYL-121 is a solid state instrument designed for the accurate estimation of disintegration time of tablets as per IP/USP standards. The instrument is designed to test two batches of six tablets simultaneously, and useful for the pharmaceutical industry. It is used in quality control labs and R & D to determine compliance with the disintegration requirement of the tablet and capsule as per USP/IP standards.

Instrument uses the latest microprocessor technology and advanced engineering techniques so as to give enhanced accuracy and reproducibility. The system has user friendly prompts, which guide you throughout the measurement process.

Microprocessor Disintegration Test Apparatus is equipped with a 20 x 4 line alphanumeric LCD display with backlit for displaying various test parameters and 15 soft touch membrane type keys with full numeric keypad that provides a convenient interface for entering numeric values. The samples being analyzed are automatically stored in the memory in different batch and sample numbers.

The instrument has a storage facility for 200 samples. It also has the facility for 20 different test setups which are retained in the memory even when the system is switched OFF. Provision has also been made for attachment of any dot matrix printer with centronics interface so that any of the stored setups/result can be printed.

The unit is provided with two glass beakers having a capacity of 1000 cc. with an arrangement to hold a temperature sensor placed in the sturdy, acrylic water bath. The large spread out stainless steel heater ensures perfectly uniform heating. The instrument has a dual channel temperature system with sensors to monitor the test temperature of disintegration beaker as well as water bath temperature. The temperature of the water bath and beaker is accurately maintained at ± 0.2 oC. The basket speed is accurately controlled and maintained as USP, IP specifications.


  •  Complies with USP, IP specifications
  •  Extremely useful for pharmaceutical labs
  •  Highly Accurate and Easy to Operate
  •  Baskets UP and DOWN movement as per IP/USP Specifications
  •  20 x 4 Line Alphanumeric LCD with Backlit
  •  15 Soft Touch Membrane Type Keys
  •  20 Setups Storage Facility
  •  200 Samples Storage Facility
  •  Printer Attachment Facility
  •  Audio Visual Indicators for System Status

Product Details

Minimum Order Quantity
1 Number
Model Name/Number
Country of Origin
Made in India

Product Brochure

Product Brochure Link here
